UPL-DL-RAINBOW-IP65
Send Order Request

Share:

Product NameRAINBOW LED Downlights
Power10W/20W/30W/35W/40W/45W
Input VoltageAC230V 50HZ
Light SourcesCREE/CITIZEN/TRIDONIC COB LEDs
LED DriverPHILIPS/OSRAM/TRIDONIC
DimmingCASAMBI/ZigBee/Triac/1-10V/DALI
Housing colorWhite/Black
Reflector colorWhite/Black/Silver/Golden/Mirror
WaterproofIP65
Lumens110-120LM/W
CCT2700K/3000K/3500K/4000K/5000K
Beam Angles45°
CRICRI≥80/90 (CRI97 is available)
Housing materialDie-casting Aluminum
Rated life-span50 000Hours
Operateing temperature.-20°C~40°C.
Storage temperature.-30°C~60°C.
CertificatesCE & RoHs


ModelPowerLamp DimensionHole Cutting
UPL-DL-3"-RAINBOW-10W10WDia100*H75mmDia90mm
UPL-DL-4"-RAINBOW-20W20WDia140*H90mmDia130mm
UPL-DL-6"-RAINBOW-30W30WDia190*H105mmDia170-175mm
UPL-DL-6"-RAINBOW-35W35WDia190*H105mmDia170-175mm
UPL-DL-8"-RAINBOW-40W40WDia230*H128mmDia200mm
UPL-DL-8"-RAINBOW-45W45WDia230*H128mmDia200mm
