IP65 CONFORMT LED Downlight
Send Order Request
Download Technical

Share:

Product NameIP65 CONFORMT LED Downlight
Power6W/10W/15W/20W/25W/30W/40W
Input VoltageAC230V 50HZ
Light SourcesCREE/CITIZEN COB LEDs
LED DriversPHILIPS/OSRAM/TRIDONIC/TCI
DimmingCASAMBI/ZigBee/Triac/1-10V/DALI
Housing colorWhite+Black
WaterproofIP65
Lumens100-110LM/W
CCT2700K/3000K/3500K/4000K/5000K
Beam Angles90°
CRICRI≥80/90 (CRI97 is available)
Housing materialDie-casting Aluminum
Rated life-span50 000Hours
Operateing temperature.-20°C~40°C.
Storage temperature.-30°C~60°C.
CertificatesCE & RoHs


ModelPowerLamp DimensionHole Cutting
UPL-DL-6W-CONFORMT-IP656WDia93*H44mmDia75mm
UPL-DL-10W-CONFORMT-IP6510WDia115*H48mmDia95mm
UPL-DL-15W-CONFORMT-IP6515WDia140*H52mmDia115mm
UPL-DL-20W-CONFORMT-IP6520WDia163*H54mmDia145mm
UPL-DL-25W-CONFORMT-IP6525WDia195*H62mmDia165-175mm
UPL-DL-30W-CONFORMT-IP6530WDia230*H62mmDia195-210mm
UPL-DL-40W-CONFORMT-IP6540WDia280*H71mmDia220-260mm
